Samsung SP1213N 120GB PATA (IDE, UDMA, EIDE) Hard Disk Drives

SP1213N product summary

SAMSUNG 120GB 7200RPM ATA133 HDD

Manufacturer
Samsung
Interface Group
PATA (IDE, UDMA, EIDE)
Interface
UDMA133
Physical Size
3.5in x 25mm
Capacity
120GB
Speed
7,200RPM

Samsung SP1213N 120GB PATA (IDE, UDMA, EIDE) Hard Disk Drives

Part Specific Options

This part has the following options to purchase.

Refurbished
1 in stock

SP1213N product details

Samsung Spinpoint P 120GB Ultra ATA Hard Drive 3.5" Ultra-ATA/133

To store and play back a limitless amount of digital media content on the web, you need a drive that provides fast and reliable data transmission. From movies to music, SAMSUNG SpinPoint drive answers all your AV needs with a drive that is so quiet, YOU WON'T EVEN KNOW IT IS THERE. - Formatted Capacity = 120GB. - Ultra ATA-133 Compatible. - Fluid Dynamic Bearing Spindle Motor Technology. - High Speed Dual Digital Signal Processor (DSP) Based Architecture. - ATA S.M.A.R.T. Compliant. - ATA Security Mode Feature Set. - ATA Host Protected Area Feature Set. - ATA Automatic Acoustic Management Feature Set. - ATA 48-bit Address Feature Set. - ATA Device Configuration Overlay Feature Set. - Multi-Burst On-The-Fly Error Correction. - NoiseGuard™. - SilentSeek™.

Features
Average latency
4.17 ms
Average seek time
8.9 ms
Bytes per sector
512
Full stroke seek time
18 ms
HDD capacity
120 GB
HDD size
3.5"
HDD speed
7200 RPM
Interface
Ultra-ATA/133
Mean time between failures (MTBF)
500000 h
Start/stop cycles
50000
Storage drive buffer size
8 MB
Track to track seek time
0.8 ms
Operational conditions
Non-operating altitude
-305 - 12200 m
Non-operating shock
350 G
Operating altitude
-305 - 3050 m
Operating relative humidity (H-H)
5 - 90%
Operating shock
63 G
Operating temperature (T-T)
5 - 55 °C
Storage relative humidity (H-H)
5 - 95%
Storage temperature (T-T)
-40 - 70 °C
Other features
Drive device, transfer rate
133 MB/s
Drive ready time
7 s
Internal
Y
Power requirements
5V°±5% / 12V°±10%
Power
Operating voltage
5 / 12 V
Power consumption (standby)
0.5 W
Weight & dimensions
Depth
146.1 mm
Height
25.4 mm
Weight
635 g
Width
101.6 mm
