MK3255GSX product summary
TOSHIBA 2.5 IN SATA300 320GB 5400 HDD
- Manufacturer
- Toshiba
- Interface Group
- SATA
- Interface
- SATA300
- Physical Size
- 2.5in
- Capacity
- 320GB
- Speed
- 5,400RPM
Toshiba MK3255GSX 320GB SATA Hard Disk Drives
Part Specific Options
This part has the following options to purchase.
- Refurbished
- Call for stock
- 493444-001
- Refurbished
- Call for stock
- 655-1551D
- Refurbished
- Call for stock
MK3255GSX product details
Toshiba 320GB 2.5" SATA 2.5" Serial ATA
The 320GB MK3255GSX drive belongs to the new MKxx55GSX series which offers capacities from 120GB to 500GB, while offering 0.0012W/GB power consumption efficiency in operation. The 5400 rpm drives have been specifically developed for devices such as ultra-portable notebooks, which must balance performance capabilities and long battery life. Due to the “Silent-Seek” technology featured in these drives, the HDDs are extremely quiet. The ultra silent single-platter drives (120GB, 160GB and 250GB) boast acoustic specifications of 20dB (seek) and 19dB (idle) making them almost indistinguishable to the human hear. The new drives incorporate the latest SATA Interface and support a 3.0Gbit/s interface data transfer rate. In addition, they offer, as an option, the Free Fall Sensor Technology to protect your drive from unexpected rough handling. The new MK3255GSX Model is ideal not only for OEMs and systems integrators under pressure to develop new mobile computing and storage products with more capacity and improved performance specifications, but as well as consumer electronic manufacturers of audio visual devices. Production of embedded hard disk drives appearing in television sets and DVD HDD recorders is increasing in Europe. The growing availability of instant audio and visual content demonstrates consumer demand for downloadable viewing. The complete drive series is halogen-free, and boasts 20% improvement in increased energy consumption efficiency, lower CO2 emmision of 95g a year less, RoHS compatible and is a certified Toshiba ECP Product. Excellent ECP is a Toshiba internal environment initiative for high value products which are exceptionally environmentally friendly.
Features
- Average latency
- 12 ms
- Bytes per sector
- 512
- Certification
- S.M.A.R.T.
- HDD capacity
- 320 GB
- HDD interface transfer rate
- 3 Gbit/s
- HDD number of cylinders
- 136.152
- HDD number of heads
- 4
- HDD size
- 2.5"
- HDD speed
- 5400 RPM
- Interface
- Serial ATA
- Mean time between failures (MTBF)
- 600000 h
- Storage drive buffer size
- 8 MB
- Track to track seek time
- 2 ms
- Type
- HDD
Operational conditions
- Non-operating shock
- 900 G
- Non-operating vibration
- 5 G
- Operating relative humidity (H-H)
- 8 - 90%
- Operating shock
- 400 G
- Operating temperature (T-T)
- 5 - 55 °C
- Operating vibration
- 1 G
Other features
- Acoustic pressure emissions
- 25 dB
- Dimensions (WxDxH)
- 69.85 x 100 x 9.5 mm
- Drive ready time
- 3.5 s
- HDD number of plates
- 2
- Internal
- Y
- Product colour
- Silver
- Supported data transfer rates
- 363 MBit/s - 952 MBit/s
Power
- Operating voltage
- 5 V
- Power consumption (off)
- 0.13 W
- Power consumption (read)
- 1.9 W
- Power consumption (standby)
- 0.18 W
- Power consumption (typical)
- 4.5 W
- Power consumption (write)
- 1.9 W
Weight & dimensions
- Depth
- 100 mm
- Height
- 9.5 mm
- Weight
- 101 g
- Width
- 69.8 mm
