DT01ABA200V product summary
TOSHIBA 2TB 25MM SATA600 32MB 5.7K HDD
- Manufacturer
- Toshiba
- Interface Group
- SATA
- Interface
- SATA600
- Physical Size
- 3.5in x 25mm
- Capacity
- 2TB
- Speed
- 5,700RPM
Toshiba DT01ABA200V 2TB SATA Hard Disk Drives
Part Specific Options
This part has the following options to purchase.
- Refurbished
- 1 in stock
DT01ABA200V product details
Toshiba 2TB DT01ABA 3.5" 2000 GB Serial ATA III
The DT01ABAxxxV Desktop hard disk drive series provides up to 3 TB capacity and features an innovative technology to deliver a greater level of power efficiency and quiet operation for energy-conscious, environmentally-friendly computers. With low power, high capacity and cool operation, these 3.5-inch (8.9cm) drives allows manufacturers to leverage the benefits of the latest components and operating systems to deliver more eco-friendly systems. This 1TB/platter hard disk drive series offers up to 5,900 RPM and an interface transfer rate of 6Gb/s. In addition, it uses the Advanced Format Technology, which is based on 4K byte-per-sector formatting and improved error-correcting code functions to provide maximum error detection and more efficient use of the storage surface area. With brilliant acoustic specifications of only 25 dB max. , the DT01ABAxxxV series has especially been designed to be integrated in set-top-boxes and digital video recorders.
Features
- HDD capacity
- 2000 GB
- HDD size
- 3.5"
- Interface
- Serial ATA III
- Read seek time
- 0.5 ms
- SMART technology
- Y
- Storage drive buffer size
- 32 MB
- Write seek time
- 0.6 ms
Operational conditions
- Non-operating shock
- 350 G
- Non-operating vibration
- 1.04 G
- Operating shock
- 70 G
- Operating temperature (T-T)
- 0 - 60 °C
- Operating vibration
- 0.67 G
- Storage temperature (T-T)
- -40 - 70 °C
Other features
- Connectivity technology
- Wired
- Data transfer rate
- 6 Gbit/s
- Rotational speed
- 5700 RPM
Packaging data
- Quantity
- 1
Power
- Operating voltage
- 5 / 12 V
- Power consumption (idle)
- 3.3 W
- Power consumption (read)
- 4.7 W
- Power consumption (standby)
- 1 W
- Power consumption (write)
- 4.7 W
Weight & dimensions
- Depth
- 147 mm
- Height
- 26.1 mm
- Weight
- 680 g
- Width
- 101.6 mm
